Isuzu chassis Aircraft Catering Truck (Electric) | |
JSTY5180JSPE Aircraft Catering Truck (Electric) It is mainly composed of the QL1180BEVELQHY type II electric chassis produced by Qingling Automobile Co., LTD., the scissed-type hydraulic lifting mechanism, the elevatable front platform, the carriage, the front and rear sliding doors, the vehicle thermal management system, and the retractable and stable foot components (360° round-view monitoring, driver monitoring system, airport special transport vehicle supervision and the management of big data flat car enterprises Table, one-button operation, Bluetooth remote control brake air conditioning system, cold storage system optional). The front platform of the Aircraft Catering Truck (Electric) can be moved back and forth, left and right, and can be connected to various types of aircraft with the height of the cabin door between (2550 ~ 6200) mm. The rated load of the carriage is 6500kg, the rated load of the fixed platform is 2200kg, the rated load of the movable platform is 800kg, and the driving range is 440km. Isuzu chassis Aircraft Catering Truck (Electric) eight parameters configuration Driving motor model: GC-TM1300-01 Travel motor controller model: GC-CU1300-01 Energy storage device assembly model: L228H01 Platform working height (mm) : 2550 ~ 6200 Body load rating (kg) : 6500 Front platform load rating (kg) : 3000 Front platform moving part load rating (kg) : 800 Adjustment range of the left and right parts of the front platform (mm) : 0 ~ 700 The expansion adjustment range of the moving part of the front platform (mm) : 0 ~ 600 Dimension of fixed part of front platform (L × W) (mm) : 2050x2265 Dimensions of the moving part of the front platform (L × W) (mm) : 950x1200 Quality (kg) : 13790 Overall dimensions (length × width × height) (mm) : 10500×2500×3700 Driving range (km) : 440 Chassis model: QL1180BEVELQHY External dimensions (length × width × height) (mm) : 7500×2500×2400 Front platform fixed part load rating (kg) : 2200 Total energy of energy storage device (kWh) : 281.92 Jiangsu Tianyi Aviation Industry Co., Ltd. Factory: No.2 Hang Kong Road High-tech zone, Jianhu county, Yancheng City, Jiangsu Province, P.R.China Shanghai Office: Room 1103, Building 35, No. 1399 Jiasong Middle Road, Qingpu District, Shanghai, China Tel: +86 21 50496068 / +86 21 50496058 / +86 400 9980 919 Mobile: +86 137 6133 5725 (As WeChat) +86 195 1651 9903 E_ mail: joinsun@jstianyi.com.cn airport.gse@jstianyi.com.cn Website: www.tianyi-gse.com ![]() | |
