S11 Yellow/Green Heat Shrink Tube | |
Introduction A flexible,flame-retardant polyolefin,yellow/green striped color. Instant identification of "ground" on wires and cables. Features Operating temperature: -40 to 125°C Minimum full recovery temperature: 125°C Shrink ratio: 2:1 & 3:1 Environmental friendly, RoHS compliant, Flame-retardant Standard Color: Yellow/Green(-45) Co-extrusion of Green/Yellow striped color Technical Data Property Test Method Requirement Tensile Strength ASTM D2671 ≥10.4 MPa Ultimate Elongation ASTM D2671 ≥200% "Heat Aging (158°C/168h) Tensile Strength Ultimate Elongation" ASTM D2671 " ≥7.3 MPa ≥100%" Water absorption (23°C/24h) ASTM D2671 ≤0.5% Low-temperature flexibility (-40°C/4h) ASTM D2671 No cracking Heat shock (225°C/4h) ASTM D2671 No cracking, dripping or flowing Dielectric breakdown ASTM D2671 ≥AC 2500V Dielectric withstand at 2500 V ASTM D2671 ≥60s Volume resistivity ASTM D2671 ≥1.0×1014Ω.cm Flammability ASTM D2671 method C Self-extinguishing within 60S Copper corrosion (158°C/16h) ASTM D2671 No corrosion Dimension Size As supplied(mm) After recovered (mm) "Standard length (m)" S11 "Inner diameter D (min.)" "Inner diameter d (max.)" "Wall thickness t (nom.)" Shrink ratio 2:1 1.0 1.0 0.7 0.28 200 2.0 2.0 1.0 0.35 200 3.0 3.0 1.5 0.38 200 4.0 4.0 2.0 0.45 200 5.0 5.0 2.5 0.45 100 6 6.0 3.0 0.50 100 7 7.0 3.5 0.50 100 8 8.0 4.0 0.55 100 9 9.0 4.5 0.55 100 10 10.0 5.0 0.55 100 12 12.0 6.0 0.60 100 14 14.0 7.0 0.60 100 16 16.0 8.0 0.70 100 18 18.0 9.0 0.70 100 20 20.0 10.0 0.80 100 25 25.0 12.5 0.90 50 30 30.0 15.0 0.95 50 35 35.0 17.5 1.00 50 40 40.0 20.0 1.00 50 50 50 25 1.00 25 60 60 30 1.10 25 70 70 35 1.20 25 80 80 40 1.30 25 90 90 45 1.50 25 100 100 50 1.70 25 Shrink ratio 3:1 3/1 3.0 1.0 0.55 200 4.5/1.5 4.5 1.5 0.60 100 6/2 6.0 2.0 0.65 100 9/3 9.0 3.0 0.75 50 12/4 12.0 4.0 0.75 50 18/6 18.0 6.0 0.85 50 24/8 24.0 8.0 1.00 25 39/13 39.0 13.0 1.50 25 Shrink ratio 3:1 (adhesive linner) 12/4 12.0 4.0 -- 1.22 18/6 18.0 6.0 -- 1.22 24/8 24.0 8.0 -- 1.22 39/13 39.0 13.0 -- 1.22 Cross Reference Tyco-Raychem: DCPT  | |
